Eclipse 5 Oxygen Concentrator Manual: Article Plan
This manual details the Eclipse 5’s operation, maintenance, and safety. It covers setup, troubleshooting, battery handling, and warranty information for optimal oxygen therapy.
The Eclipse 5 oxygen concentrator is a portable, lightweight device designed to deliver supplemental oxygen to individuals requiring respiratory support. Manufactured with advanced technology, it extracts oxygen from ambient air, providing a reliable and convenient oxygen source for improved quality of life. This manual serves as a comprehensive guide for users, caregivers, and healthcare professionals, detailing the safe and effective operation of the Eclipse 5.
Understanding the device’s features and functionalities is crucial for maximizing its benefits. The Eclipse 5 boasts a user-friendly interface, multiple power options, and robust safety mechanisms. It’s designed for both home and travel use, offering flexibility and independence to those who rely on oxygen therapy. Prior to use, carefully review this manual to ensure proper setup and operation.
What is an Oxygen Concentrator?
An oxygen concentrator is a medical device that extracts oxygen from the air around you, providing a higher concentration of oxygen than is naturally present. Unlike oxygen tanks that store compressed gas, concentrators pull in ambient air – approximately 21% oxygen, 78% nitrogen, and other gases – and filters out the nitrogen, leaving a concentrated stream of oxygen for the user.
The Eclipse 5 utilizes a molecular sieve to achieve this separation. This adsorbent material selectively captures nitrogen, allowing oxygen to pass through. Oxygen concentrators are a convenient and cost-effective alternative to traditional oxygen delivery methods, offering a continuous supply of oxygen without the need for refills.
Understanding the Eclipse 5’s Functionality
The Eclipse 5 oxygen concentrator functions by drawing in room air and utilizing a molecular sieve to separate oxygen from other gases. This process delivers a consistent and reliable source of supplemental oxygen. The device continually monitors its output via the Oxygen Concentration Status Indicator (OCSI), providing visual alerts – green, yellow, or red – to ensure optimal performance.
Furthermore, the Eclipse 5 is designed for portability, often featuring battery operation for use on the go. Understanding its components, alarm functions, and proper maintenance is crucial for safe and effective oxygen therapy. Regular filter checks and adherence to cleaning guidelines are also essential.
Key Features of the Eclipse 5
The Eclipse 5 boasts several key features designed for user convenience and reliable oxygen delivery. Its compact and lightweight design enhances portability, while the integrated OCSI (Oxygen Concentration Status Indicator) provides real-time monitoring of oxygen purity with clear visual alerts. Battery operation extends usability beyond traditional power sources, ideal for travel.
Furthermore, the device supports various therapies and includes robust alarm functions for immediate issue identification. The Eclipse 5 is compatible with the Eclipse Marketplace and supports languages like Java, C/C++, and Python. It’s built for stable, production-level performance, backed by a comprehensive warranty.
Oxygen Concentration and Purity
The Eclipse 5 is engineered to deliver consistent and reliable oxygen concentration. It draws in ambient air, approximately 21% oxygen, and utilizes a molecular sieve to separate oxygen from other gases like nitrogen. This process results in a highly purified oxygen stream for therapeutic use.
The integrated OCSI continuously monitors the oxygen output, ensuring it meets prescribed levels. The OCSI employs a color-coded system – green for normal, yellow for alert, and red for alarm – providing immediate feedback on oxygen purity. Maintaining optimal purity is crucial for effective oxygen therapy and patient well-being.
Portability and Battery Operation
The Eclipse 5 is designed with portability in mind, allowing users to maintain an active lifestyle while receiving necessary oxygen therapy. Its compact size and lightweight design facilitate easy transport. When traveling, the device should be treated as checked luggage, and crucially, the battery must be removed prior to shipping for safety compliance.
Optional battery packs extend the operational time away from traditional power sources. Proper battery handling and storage are essential for maximizing lifespan and ensuring reliable performance. Refer to the dedicated battery section for detailed instructions on charging, usage, and safe storage practices.
Setting Up the Eclipse 5
Proper setup is crucial for safe and effective operation of the Eclipse 5. Begin with a thorough initial inspection of all components, verifying that everything is present and undamaged. Ensure the device is placed on a stable, level surface with adequate ventilation around the air intake areas.
Next, connect the Eclipse 5 to a suitable power source, adhering to the specified power requirements detailed in the technical specifications section. Before initiating use, carefully check the filter to ensure it is clean and unobstructed. Understanding this manual is paramount; if unclear, contact your equipment provider.
Initial Inspection and Components
Upon receiving your Eclipse 5, carefully inspect the packaging for any signs of damage during transit. Once opened, verify the presence of all listed components: the Eclipse 5 unit itself, a power cord, a user manual (this document!), and potentially, a carrying case and additional filters.
Examine the device for any visible defects, such as cracks or loose parts. Confirm the integrity of the air intake filters and the overall cleanliness of the unit. Prior to 2025-09, the Eclipse Terminal was maintained by the Eclipse CDT project, highlighting ongoing development. Familiarize yourself with the location of key features before proceeding.
Connecting to a Power Source
The Eclipse 5 is designed to operate on standard AC power. Before connecting, ensure the power outlet matches the device’s voltage requirements – consult the ‘Technical Specifications’ section for details. Insert the provided power cord securely into the Eclipse 5’s power input and then into a grounded electrical outlet.
Power requirements are crucial for optimal performance. The device supports a range of voltages, detailed in the specifications. Remember that when shipping, the battery must be removed. The Eclipse Platform, with contributions from projects like Eclipse CDT, ensures stable operation. Verify the connection is firm to prevent interruptions during use.
Preparing for Use: Filter Check
Prior to each use, inspect the Eclipse 5’s air filters. These filters are vital for ensuring clean, purified oxygen delivery. Locate the filter access panel – refer to ‘Initial Inspection and Components’ for its location. Gently remove the filter and visually check for dust, debris, or discoloration.
A dirty filter restricts airflow, potentially impacting oxygen concentration. Replace the filter if it appears soiled, following the ‘Filter Replacement Schedule’ guidelines. The Eclipse Platform, developed with contributions from Eclipse CDT, emphasizes reliability. Regular filter checks, alongside adherence to the manual, guarantee optimal performance.
Operating the Eclipse 5
To begin operation, ensure the Eclipse 5 is connected to a suitable power source, as detailed in ‘Connecting to a Power Source’. Press the power button to initiate the device. The oxygen concentration status indicator (OCSI) will illuminate, undergoing a self-test. Allow the device a brief period to reach the set oxygen flow rate.
Adjust the flow settings using the control knob, referencing ‘Adjusting Oxygen Flow Settings’ for appropriate levels. The Eclipse 5, supported across Windows, Mac, and Linux, prioritizes user control. Monitor the OCSI – green indicates normal function. Familiarize yourself with alarm functions for safe and effective use.
Powering On and Off
To power on the Eclipse 5, firmly press the power button located on the control panel. The device will initiate a self-test sequence, indicated by the illumination of the oxygen concentration status indicator (OCSI). Allow a short period for the unit to reach the selected flow setting. To power off, press the power button again.
Ensure the device completely shuts down before disconnecting from the power source. The Eclipse 5, compatible with various platforms, is designed for simple operation. Always observe the OCSI during startup and shutdown. Proper powering on/off ensures longevity and optimal performance.
Adjusting Oxygen Flow Settings
The Eclipse 5 allows for precise oxygen flow adjustment to meet individual therapy needs. Utilize the flow rate control knob, typically located on the front panel, to select the desired setting. The flow rate is displayed in liters per minute (LPM). Consult your healthcare provider to determine the appropriate flow rate for your condition.
Adjustments should be made gradually, observing the patient’s response. Ensure the selected flow rate aligns with the prescribed medical order. The device supports a range of flow settings, catering to diverse patient requirements. Regular monitoring is crucial for optimal therapeutic benefit.
Understanding the Oxygen Concentration Status Indicator (OCSI)
The Eclipse 5 incorporates an Oxygen Concentration Status Indicator (OCSI), a vital safety feature continuously monitoring oxygen output. This system employs a multi-color light display – green, yellow, and red – alongside an audible buzzer to signal the device’s operational status; The OCSI provides immediate feedback on oxygen purity and system performance.
Regularly observe the OCSI during operation. A green light signifies normal function, while yellow indicates an alert requiring attention. A red light signals an alarm, demanding immediate action. Understanding these indicators is crucial for safe and effective oxygen therapy.
OCSI Indicators: Green, Yellow, and Red
The Eclipse 5’s OCSI utilizes a color-coded system for clear status communication. A green indicator signifies normal operation, confirming the device delivers the prescribed oxygen concentration without issue. Yellow alerts the user to a potential problem, such as a slight decrease in oxygen purity, requiring monitoring. It’s a warning to investigate.
A red OCSI light and accompanying buzzer signal a critical alarm condition. This indicates a significant drop in oxygen concentration, potentially endangering the patient. Immediate troubleshooting or switching to a backup oxygen source is essential. Always prioritize patient safety when a red indicator is present.
Alarm Functions and Troubleshooting
The Eclipse 5 incorporates multiple alarms to alert users to potential issues. Low oxygen concentration triggers a visual and audible alarm, demanding immediate attention. Power failures, high/low flow rates, and system malfunctions also activate alarms. Refer to the error code section for specific troubleshooting steps.
Troubleshooting often begins with verifying power connections and filter cleanliness. If alarms persist, consult the device’s error code list to pinpoint the problem. For unresolved issues, contact qualified service personnel. Never attempt repairs yourself, as this could void the warranty and compromise safety.
Using the Eclipse 5 with Different Therapies
The Eclipse 5 is versatile, supporting various oxygen delivery methods. It’s compatible with nasal cannulas for long-term therapy, and masks for increased oxygen concentration. Ensure proper fit and secure connections for each therapy type. Adjust flow settings according to your healthcare provider’s prescription.
Consider humidity when using the Eclipse 5, especially with tracheostomy tubes. A humidifier bottle can prevent dryness and discomfort. Always follow your physician’s guidance regarding appropriate therapy settings and duration. Regular monitoring of oxygen saturation levels is crucial for optimal treatment outcomes.
Maintenance and Cleaning
Regular maintenance ensures the Eclipse 5’s longevity and optimal performance. Clean the exterior with a damp cloth and mild detergent. Avoid harsh chemicals or abrasive cleaners. The air intake filters require periodic replacement – consult the filter replacement schedule for specific intervals. Inspect the humidifier bottle (if used) daily for cleanliness and water levels.
Disinfection is crucial to prevent bacterial growth. Use a hospital-grade disinfectant, following the manufacturer’s instructions. Always disconnect the device from power before cleaning. Proper cleaning and filter changes maintain oxygen purity and device reliability, contributing to effective therapy.
Filter Replacement Schedule
Maintaining optimal performance requires adhering to a strict filter replacement schedule. The Eclipse 5 utilizes intake filters to prevent dust and particles from entering the system. These filters should be inspected monthly and replaced every three months, or more frequently in dusty environments. Frequent inspections are vital for ensuring consistent oxygen delivery.
Replacement filters are readily available from authorized suppliers. Always use genuine Eclipse 5 filters to guarantee compatibility and effectiveness. A clogged filter reduces oxygen output and strains the compressor. Documenting filter changes helps track maintenance and ensures consistent device operation, maximizing therapeutic benefits;
Exterior Cleaning Procedures
Regular exterior cleaning maintains hygiene and extends the Eclipse 5’s lifespan. Before cleaning, always disconnect the device from the power source. Use a soft, slightly damp cloth with mild soap and water to wipe down the exterior surfaces. Avoid abrasive cleaners or solvents, as they can damage the casing.
Pay particular attention to areas frequently touched, like the control panel and handle. Ensure no moisture enters the air intake vents. After cleaning, dry the exterior thoroughly with a clean, dry cloth. Do not immerse the device in water. Consistent cleaning prevents the buildup of dust and contaminants, promoting safe and reliable operation.
Disinfection Guidelines
Maintaining a sterile environment is crucial when using the Eclipse 5, especially for multiple users. Disinfection should occur regularly, following these guidelines. Always disconnect the device from power before disinfecting. Use an EPA-registered disinfectant wipe or solution approved for medical devices.
Carefully wipe down all exterior surfaces, focusing on high-touch areas like the control panel and handle. Avoid spraying liquids directly onto the device; apply to a cloth first. Ensure the disinfectant is compatible with the device’s materials – avoid harsh chemicals. Allow the disinfectant to dwell for the manufacturer’s recommended time before wiping dry with a clean cloth.
Safety Precautions
Oxygen supports combustion, so extreme caution is necessary. No smoking or open flames should be near the Eclipse 5. Keep the device away from flammable materials like oil, grease, and alcohol. Ensure adequate ventilation during operation. Do not modify or disassemble the device; this could compromise its safety and performance.
Always follow the prescribed flow settings determined by your healthcare professional. Regularly inspect the tubing for cracks or leaks. When shipping, the battery must be removed. Understand this manual thoroughly; if unclear, contact your provider. Improper use can lead to injury or device malfunction.
Oxygen Safety Considerations
Oxygen is a powerful oxidizer and supports combustion. Never use the Eclipse 5 near open flames, sparks, or sources of ignition. Avoid using oil-based products (lotions, creams) while using oxygen, as they are flammable. Ensure the room is well-ventilated to prevent oxygen enrichment, which increases fire risk.
Do not operate the device in a hyperbaric chamber or near flammable anesthetics. Regularly check for leaks in the tubing and connections. The Eclipse 5 is for individual use only; do not share accessories. Always follow your healthcare provider’s instructions regarding oxygen use and safety.
Traveling with the Eclipse 5
When traveling with the Eclipse 5, always check with your airline regarding their specific oxygen concentrator policies. The device is checked as luggage, and the battery must be removed before transport. Ensure the concentrator is properly secured to prevent damage during transit.
Carry a copy of your prescription and a letter from your physician stating your need for supplemental oxygen. Familiarize yourself with power adapter requirements at your destination. Always maintain the device’s original packaging for easier transport and protection. Confirm battery regulations for air travel with your carrier.
Battery Handling and Storage
Proper battery handling is crucial for the longevity and performance of your Eclipse 5. Always remove the battery when shipping the oxygen concentrator. Store batteries in a cool, dry place, away from direct sunlight and extreme temperatures.
Avoid short-circuiting the battery terminals. Only use the charger specifically designed for the Eclipse 5 battery. Do not disassemble or attempt to repair the battery pack. Regularly check the battery’s charge level and avoid prolonged periods of complete discharge. Dispose of used batteries responsibly, following local regulations.
Troubleshooting Common Issues
Addressing issues promptly ensures continued reliable operation of your Eclipse 5. Low oxygen concentration alerts require immediate attention – check the filter and ensure proper airflow. If the device isn’t powering on, verify the power source and battery charge.
Pay attention to error codes; consult the manual for their specific meanings. A malfunctioning OCSI (Oxygen Concentration Status Indicator) may indicate a system fault. If problems persist, do not attempt self-repair; contact qualified service personnel. Remember to always prioritize safety and consult the full manual for detailed guidance.
Low Oxygen Concentration Alerts
A yellow OCSI light signals a potential low oxygen concentration, requiring immediate user attention. First, verify the nasal cannula is securely connected and undamaged. Next, inspect the air filter for obstructions and clean or replace it as needed. Ensure the device isn’t positioned near obstructions hindering airflow.
If the alert persists, check for kinks in the tubing. A red OCSI light indicates a critical low oxygen level; discontinue use and contact your healthcare provider. Always prioritize safety and consult the full manual for detailed troubleshooting steps and potential causes of these alerts.
Device Not Powering On
If the Eclipse 5 fails to power on, first confirm the power cord is securely connected to both the device and a functioning power outlet. Check the fuse within the power cord for any signs of damage or breakage; replace if necessary. If using battery power, ensure the battery is fully charged and properly installed.
Verify the power switch is in the ‘ON’ position. If the issue persists, attempt a different power outlet to rule out electrical problems. Consult the troubleshooting section of this manual or contact customer support if these steps don’t resolve the problem.
Error Codes and Their Meanings
The Eclipse 5 utilizes error codes to indicate specific malfunctions. A flashing red OCSI light accompanied by a numerical code signals a problem requiring attention. Code E01 may indicate a sensor failure, while E02 could signify a compressor issue. E03 often relates to an internal system error, necessitating professional service.
Refer to the complete error code list in Appendix A for detailed explanations and recommended actions. Ignoring error codes can compromise device performance and patient safety. Contact customer support immediately if you encounter an unfamiliar or recurring error code.
Technical Specifications
The Eclipse 5 boasts a compact design with dimensions of 10.5” H x 7.5” W x 12.5” D and a weight of approximately 10.8 lbs (4.9 kg). It operates on 100-240V AC, 50/60Hz, accommodating international power standards. The oxygen flow range is 1-5 LPM (liters per minute), adjustable to meet individual prescription needs.
Oxygen concentration is maintained between 90-96%, ensuring therapeutic efficacy. Battery operation provides up to 8 hours of runtime, depending on flow settings. The device supports various sieve bed types for optimized performance. Detailed specifications are subject to change; consult the latest product documentation.
Dimensions and Weight
The Eclipse 5 is engineered for portability without compromising performance. Its compact dimensions are 10.5 inches (26.7 cm) in height, 7.5 inches (19.1 cm) in width, and 12.5 inches (31.8 cm) in depth. These measurements facilitate easy placement in various environments, including travel settings.
Weighing approximately 10.8 pounds (4.9 kilograms), the device strikes a balance between robustness and manageable weight for the user. This lightweight design, coupled with its size, makes the Eclipse 5 a convenient option for individuals requiring supplemental oxygen on the go. Accurate measurements are crucial for travel compliance.
Power Requirements
The Eclipse 5 oxygen concentrator is designed for versatile power options, ensuring uninterrupted oxygen delivery. It operates on a standard AC power input of 100-240 volts, 50/60 Hz, making it adaptable to various international power grids. This broad voltage range eliminates the need for transformers in many locations.
The device also supports DC power via a dedicated DC power cable, typically 12-16V DC. Furthermore, the Eclipse 5 is compatible with its optional long-lasting battery, providing hours of portable operation. Proper voltage and amperage are critical for safe and efficient performance; always verify compatibility.
Oxygen Flow Range
The Eclipse 5 oxygen concentrator offers a broad oxygen flow range, catering to diverse patient needs and physician-prescribed settings. It delivers a continuous flow of oxygen from 1 to 7 liters per minute (LPM), allowing for precise titration to achieve the optimal oxygen saturation level.
This adjustable flow rate makes the Eclipse 5 suitable for various therapies, including long-term oxygen therapy and exercise-induced hypoxia. The device’s ability to deliver low flow rates is beneficial for patients requiring minimal oxygen support, while higher settings accommodate those with greater respiratory demands. Accurate flow setting is crucial for effective treatment.
Warranty Information
The Eclipse 5 oxygen concentrator is backed by a comprehensive warranty, providing peace of mind and protecting against manufacturing defects. A standard warranty covers the device for a period of three years from the original date of purchase, encompassing parts and labor for repairs. The battery is typically covered for one year, reflecting its limited lifespan.
Warranty coverage is contingent upon proper use and adherence to the guidelines outlined in this manual. Damage resulting from misuse, accidents, or unauthorized modifications will void the warranty. Registration of the device is required to activate the warranty, ensuring seamless claims processing.
Registration Process
Registering your Eclipse 5 oxygen concentrator is crucial for activating the warranty and receiving important product updates. The registration process is straightforward and can be completed online through the manufacturer’s website. You will need the device’s serial number, found on the unit’s label, and your purchase details.
Alternatively, you can register by completing the physical registration card included with your device and mailing it to the designated address. Upon successful registration, you will receive a confirmation email or postcard. Registration ensures access to customer support, recall notifications, and extended service options, maximizing the lifespan of your Eclipse 5.
Coverage Details
The Eclipse 5 oxygen concentrator warranty covers defects in materials and workmanship under normal use. This coverage typically begins on the date of purchase and extends for a specified period, often varying based on component type. The warranty does not cover damage resulting from misuse, accidents, unauthorized repairs, or normal wear and tear.
Specifically, the warranty may offer extended coverage for the compressor and sieve beds, while other parts have a shorter coverage duration. To maintain warranty validity, adhere to the recommended maintenance schedule outlined in this manual. Proof of purchase is required for all warranty claims.
Contacting Customer Support
For any questions, concerns, or assistance regarding your Eclipse 5 oxygen concentrator, our dedicated customer support team is readily available. We offer multiple channels for support, including a toll-free telephone hotline, email correspondence, and a comprehensive online support portal. Our knowledgeable representatives can assist with troubleshooting, warranty inquiries, and general product information.
Please have your device’s serial number and date of purchase readily available when contacting support to expedite the assistance process. Visit our website for frequently asked questions and downloadable resources. We are committed to providing prompt and effective support to ensure your satisfaction with the Eclipse 5.
